The Blackmagic Design ATEM Mini Extreme is a professional 8-input live production switcher designed for broadcasters and content creators who need extensive connectivity in a portable form factor. It significantly expands upon the capabilities of the smaller models, offering a massive eight HDMI inputs, each with dedicated standards conversion, allowing you to mix and match various camera resolutions and frame rates up to 1080p60 without external hardware.
This switcher is built for high-end multi-camera streaming, featuring two independent USB-C ports that can operate as a high-definition webcam for software like Zoom or record your program directly to external SSDs in H.264 format. It includes a powerful internal hardware streaming engine for direct transmission via Ethernet to platforms like YouTube and Twitch, and it can even tether to a 5G or 4G phone as a primary or backup internet source. For advanced visual effects, the Extreme features four upstream chroma keyers, two independent DVEs, and a unique SuperSource multi-layer processor that adds four extra DVE layers for complex picture-in-picture layouts.
The hardware is designed for tactile, professional control with a comprehensive front panel that includes dedicated buttons for audio mixing, recording, and streaming. It offers two HDMI "AUX" outputs that can be independently routed, plus a customizable 16-way Multiview to monitor all eight inputs, recording status, and audio levels on a single screen. With a built-in Fairlight audio mixer featuring 6-band parametric EQ, dynamics, and a dedicated headphone output for real-time monitoring, the ATEM Mini Extreme is a complete, broadcast-ready studio in a single compact unit.
The Blackmagic Design ATEM Mini Extreme is a professional 8-input live production switcher designed for broadcasters and content creators who need extensive connectivity in a portable form factor. It significantly expands upon the capabilities of the smaller models, offering a massive eight HDMI inputs, each with dedicated standards conversion, allowing you to mix and match various camera resolutions and frame rates up to 1080p60 without external hardware.
This switcher is built for high-end multi-camera streaming, featuring two independent USB-C ports that can operate as a high-definition webcam for software like Zoom or record your program directly to external SSDs in H.264 format. It includes a powerful internal hardware streaming engine for direct transmission via Ethernet to platforms like YouTube and Twitch, and it can even tether to a 5G or 4G phone as a primary or backup internet source. For advanced visual effects, the Extreme features four upstream chroma keyers, two independent DVEs, and a unique SuperSource multi-layer processor that adds four extra DVE layers for complex picture-in-picture layouts.
The hardware is designed for tactile, professional control with a comprehensive front panel that includes dedicated buttons for audio mixing, recording, and streaming. It offers two HDMI "AUX" outputs that can be independently routed, plus a customizable 16-way Multiview to monitor all eight inputs, recording status, and audio levels on a single screen. With a built-in Fairlight audio mixer featuring 6-band parametric EQ, dynamics, and a dedicated headphone output for real-time monitoring, the ATEM Mini Extreme is a complete, broadcast-ready studio in a single compact unit.
